Description
Dominate your market with the ACU110’s industry-leading 110-ton capacity that handles the largest commercial aircraft including A380s and 747-8s. You’ll capture premium revenue from airlines operating ultra-wide-body aircraft that require maximum cooling power. The triple independent refrigerant circuits deliver unmatched reliability – even with two circuits down, you maintain operational capability. Your competitive advantage grows with the ability to service aircraft other ground support providers can’t handle, commanding higher rates and securing long-term contracts with major carriers.
Features and Benefits
- Equipped with independent refrigerant circuits using R410A refrigerant
- Diesel-powered generator with a 4-stroke, water-cooled engine operating at 1,500 rpm
- Control board with engine start/stop, fuel level display, and emergency stop button
- Includes safety features like alarms for compressor overheating, high/low coolant pressure, and low fuel
- Optional features include 28 VDC output, 200/115 VAC 400 Hz, air heater, and truck-mounted configuration
| Characteristics | |
|---|---|
| Nominal Cooling Capacity of Compressor @ 60 Hz | 110 tons |
| Independent Refrigerant Circuits | 3 |
| Nominal Air Flow at PCA Outlet | 290 kg/min |
| Pressure at PCA Outlet | 7000 PA |
| Ambient Conditions / Sea Level | DB 35°C – 48% RH |
| Power Supply | 400 V / 50 Hz |
| Air Outlet | 1 |
| Refrigerant | R410A |
| Main Dimensions | |
|---|---|
| Length | 6,200 mm |
| Width | 2,280 mm |
| Height | 2,180 mm |
