Narrow Body Tow Tractor Diesel

PT2690D

PT2690 - Specification SheetPT2690 - Specification Sheet

Avro ‘next generation’ diesel aircraft tow tractors are leading edge performance, design, functionality. Designed to exceed expectations and deliver extraordinary ROI. Each tow tractor features standard functionality such as hydraulic steering, front and rear towing couplers, four wheel drive and steering, complete cab enclosure including windshield and wiper kit, Curtis controller with self-diagnosis functionality, vacuum assist hydraulic brakes, complete telematics for remote diagnostics and monitoring, along with our managed maintenance program.

Product Details

  • Hydraulic 4 wheel steering
  • Front and rear towing couplers
  • Standard heated cab enclosure with front windshield and rear wiper kits
  • Curtis controller with self-diagnosis function
  • Vacuum assist hydraulic breaks
  • Complete telematics for remote diagnostics real-time notification and pre/post start.

Model: PT2690D
Power Type: DIESEL
Service Weight: 16,500kg

DIMENSIONS
Size (L x W x H): 223” (5660mm)/ 200” (5080mm) x 87” (2200mm) x 83” (2110mm)
Wheelbase: 91” (2300mm)
Overhang (F/R): 87” (2210mm) / 45” (1150mm)
Towing Couplers Height (F/R): 17” (430mm) / 17” (430mm)
Ground Clearance: 9” (230mm)

PERFORMANCE PARAMETER
Speed (No Load): 23km/hr
Front Axle Load: 8250kg
Rear Axle Load: 8250kg
Max Drawbar Pull: 26,900lb (120kN)

ENGINE
Engine Model: QSB4.5-C110
Manufacturer: Cummins
Rated Output (kW/r/min): 82/2200
Rated Torque (N – m/r/min): 488/1500
Cylinders 4

TRANSMISSION
Model: DANA T12000
Shift Configuration (Fwd/Rvs): 4/3
