120 Gallon Aircraft Lavatory Cart

Please Request a Quote for Pricing

Product Information

Avro’s lavatory cart model AV-LVC-120 is built strong using heavy gauge steel and is protected by a tough powder coat finish and steel identification tag for inventory asset tracking.  This lavatory cart utilises fifth wheel steering with full 360 degree rotation and is highly manoeuvrable in tight spaces. It also features an ergonomic torsion relief tow bar that when released, will not hit the ground.  Another feature of this cart is its tow bar activated braking system, which applies the break with the use of the tow bar. The cart is the perfect towable cart for servicing corporate aircraft all the way up to small regional jets as it is equipped with a 90 gallon poly waste tank and 30 gallon poly blue water tank.  This lavatory cart is powered with a 12 volt electric pump and has a winterization package installed in order to keep all components and liquid from freezing.  An on board battery charger provides opportunistic charging capabilities when the cart is not in service.  The lavatory cart comes delivered with everything needed to begin aircraft lavatory service including aircraft hoses and couplings for both the waste and flush side of the operation as well as liquid flow meter.

Specifications

  • Length:109”
  • Width: 47”
  • Height: 48”
  • Waste Tank Capacity: 90 Gal
  • Flush Tank Capacity 30 Gal
  • 12 Volt Electric Pump – 4.7 GPM
  • Winterization Package
  • 1 Year Manufacturer’s Warranty



Optional Equipment

  • Stainless Steel Body Panels
  • Stainless Steel Tanks
  • Closed Dump System
  • Programmable Meter
  • Custom Colors

Supporting Documents

Product SKU

AV-LVC-120
